Desktop Air Quality Monitor AM7000

Name: Desktop Air Quality Monitor AM7000
Brand: Cubic Sensor and Instrument Co.,Ltd.

AM7000 is a 6 in 1 intelligent desktop indoor air quality monitor with fashionable and compact design. It integrates with Cubic developed advanced air quality sensor module, which can monitor indoor air quality and output real-time data of PM2.5, CO2, HCHO, VOC, RH&T.

Cubic could provide complete AM7000 end-to-end solutions. Based on the MQTT protocol, Cubic could develop smartphone apps or webpage based on requirements, and could also achieve data integration with public or private cloud platforms. Additionally, we offer hardware customization including appearance design and sensor configuration, etc.

Features Specification Structure Communication Application

Features of Desktop Air Quality Monitor AM7000

Build in Wi-Fi and Bluetooth, data transfer via MQTT;
Real-time output CO2, PM2.5, HCHO/TVOC and RH&T;
Auto-calibration, maintenance-free;
Desktop monitor, USB power supply;
OEM/ODM available (sensor configuration, appearance design, PCBA design, software development, etc.)

Specification of Desktop Air Quality Monitor AM7000

Working principle	CO2: Non-Dispersion Infrared (NDIR); PM: Light scattering, HCHO/VOC: Electrochemical
Measurement range	CO2: 400~5000ppm; PM2.5: 0~999μg/m³
	Temperature: -10°C~50°C; Relative Humidity: 0%~95%RH
	Formaldehyde：0~1.000mg/m³
CO2 accuracy	± (50ppm+5% of reading) /± (30ppm+3% of reading) is optional
PM accuracy	PM2.5: 0~100μg/m³, ±10μg/m³; >100μg/m³, ±10% of reading
Temperature Accuracy	±1°C (0°C ~50°C)
Humidity Accuracy	±8% (0%~95%RH)
Formaldehyde Accuracy	<=0.100mg/m³：±0.03mg/m³; ＞0.100mg /m³：±30% of read
UI Screen	2.8 inch TFT LCD screen
Communication protocol	MQTT
Power supply	DC 5V
Working Condition	-10°C~50°C,0~95%RH (non-condensing)
Storage condition	-20℃~60℃,0~95%RH (non-condensing)
Dimension	W90H85D53 (mm)

Structure of Desktop Air Quality Monitor AM7000

1. External Casing: AM7000 is usually enclosed in a durable casing to protect its internal components and provide stable housing.

2. Display Panel: A prominent display panel is integrated into the monitor, showing real-time measurement data. This allows users to easily assess the level of indoor air quality by different colors.

3. Air Quality Sensors: Various air quality sensors are built into the AM7000 to measure and detect specific air quality parameters.

4. Air Intake: AM7000 usually has an intake or inlet through which it pulls in ambient air for analysis.

5. Power Supply: USB cable, 5V DC

6. Accessories: USB cable X1, Datasheet X1, Formaldehyde module X1

7. Approval CE certification

Communication of Desktop Air Quality Monitor AM7000

WIFI and Bluetooth as default, other communication methods such as Lora, EnOcean can be customized according to customer requirements.

Application of Desktop Air Quality Monitor AM7000

AM7000 is generally applicable for indoor air quality monitoring in settings like offices, living rooms, classrooms, etc. Its traffic light will alert users when air quality declines and instruct them to appropriately ventilate. In the meanwhile, The level of carbon dioxide can significantly affect air quality in the agricultural, food, pharmaceutical, refrigeration and brewing sectors, CUBIC Control also provides mini CO2 detectors for the ventilation system, trust us for your needs.
